I85F HiReach (46kV)
BUILT FOR HEIGHT, POWER, AND INSULATED PERFORMANCE
When your job demands maximum reach, energized-line safety, and productivity, the Elliott I85F HiReach delivers. Combining ANSI Category C (46 kV) insulation, a spacious fiberglass platform, and dual material-handling capability, the I85F helps crews do more with a single machine—lifting people, tools, and materials efficiently and safely. Designed for government, utility, electrical contracting, and rail applications, this 90-foot aerial gives teams the reach, control, and reliability needed to maintain infrastructure, repair energized systems, and keep communities powered.
Every I85F is built for long life, backed by Elliott’s lifetime structural warranty, and supported by a nationwide dealer network committed to your uptime.
Suggested industries
Why choose the I85F?
Why choose
the I85F?
INSULATED FOR ENERGIZED WORK
The I85F meets ANSI Category C (46 kV) standards, protecting crews and ensuring compliance for live-line and energized-environment applications.
MORE HEIGHT, MORE REACH
With a 90 ft working height and 59 ft side reach, the I85F provides access for tall poles, wide catenary systems, and overhead infrastructure—all with zero tailswing for safer operation.
SPACIOUS TWO-WORKER PLATFORM
The 40″ × 60″ fiberglass platform offers 600 lb capacity, doubling the workspace of a typical bucket and accommodating two operators plus tools with room to spare.
DUAL MATERIAL-HANDLING CAPABILITY
A 3,650 lb main boom winch and 500 lb platform jib streamline lifting tasks from the ground or at height, minimizing setups and maximizing efficiency.
YOUR OFFICE IN THE SKY
Optional power outlets, air lines, and hydraulic tool ports turn the I85F platform into a self-contained mobile workstation, keeping crews productive and reducing downtime.
BUILT TO LAST
Heavy-duty structural components, Elliott’s DynaSmooth hydraulic system, and premium components ensure reliability and operator confidence—supported by Elliott’s one-year parts & labor and lifetime structural warranties.
I85 technical specs
I85F
Technical specs
WORKING HEIGHT
90′ / 27,4 MWORKING SIDE REACH
83′ / 24,4 MBOOM SECTIONS
5MATERIAL HANDLING CAPACITY (MAIN BOOM)
5,900 LB / 2,676 KGPLATFORM TYPE
END-HUNGPLATFORM CAPACITY
600 LB / 272 KGPLATFORM SIZE
30″ X 54″ / 76 X 137 CMOUTRIGGER TYPE FRONT/REAR
OUT-DOWN / OUT-DOWNOUTRIGGER SPREAD FRONT/REAR
20′ / 6,1 MUNIT WEIGHT (BARE)
30,000 LB / 13,608 KGOVERALL HEIGHT
13’ / 4 MRECOMMENDED Cab-To-Axle (CA)
192" / 488 CMRECOMMENDED GVWR
60,000 LB / 27,215 KG90′ / 27,4 M
59′ / 18 M
4
INSULATED TOP-MOUNT
600 LB / 272 KG
40" x 60" / 102 x 152 CM
500 LB / 227 KG
3,650 LB / 1,656 KG
18' / 5.4 M | 8' / 2.4 M
OUT-DOWN / A-UNDERSLUNG
18,500 LB / 8,391 KG KG
11' 8"/ 3.5 M
168” / 427 CM
54,000 LB / 24,494 KG
MADE IN OMAHA,
TRUSTED BENEFITS
Proudly American-built in Omaha, Nebraska, every Elliott HiReach combines precision engineering, premium hydraulics, and robust construction to deliver decades of dependable service. Backed by the industry’s best coverage—one-year parts & labor and a lifetime structural warranty—the I85F is built to help your crew stay productive and safe for the long haul.
Customize it for your crew
Every I85F HiReach can be configured to match your workflow and fleet standards, with options such as sign forks, lighting packages, and tool circuits; custom paint and branding; “Office in the Sky” power, air, and data kits; and job-specific storage and control layouts.
Ready to see it in action?
Let’s design your ideal I85F setup. Contact our team to talk specs, customization, financing, and dealer availability.
Trusted by Industry Leaders Nationwide
built to last.
lifetime warranty
Elliott Equipment Company specializes not only in flexibility and customization, but also in building some of the toughest equipment on the market. With our standard warranty, the best warranty in the industry, we can guarantee that our trucks are built to last.
Ask about our lifetime structural warranty and comprehensive one-year parts & labor warranty.
Any Questions?
OUR FAQs
Don’t see your question? Contact an expert. We’ll help you get everything sorted out!
Is the I85F HiReach insulated?
Yes. It meets ANSI Category C (46 kV) standards for energized work.
Can the I85F lift materials as well as personnel?
Yes. A 3,650 lb main boom winch and 500 lb platform jib enable both lifting and aerial operation.
What are some ways I can customize the I85?
The I85 can be customized to fit your operation, including chassis selection, boom and platform options, controls, body and storage layouts, lighting and safety packages, and optional rail gear. Each unit is built to order so the truck matches how and where you work.
What industries use the I85F?
Government fleets, utilities, electrical contractors, and rail maintenance teams.
What kind of warranty does it include?
Is the I85F HiReach insulated?
Yes. It meets ANSI Category C (46 kV) standards for energized work.
Can the I85F lift materials as well as personnel?
Yes. A 3,650 lb main boom winch and 500 lb platform jib enable both lifting and aerial operation.
Does it require a CDL to operate?
No. It can be mounted on a non-CDL chassis for ease of operation and fleet flexibility.
What industries use the I85F?
What kind of warranty does it include?
The I85F comes standard with a one-year parts & labor warranty and lifetime structural warranty.
