1881TM BoomTruck  #8078

Contact Details

Dealership: Nixon-Egli Equipment Company
Sales Contact: Gavin Singleton
Phone Number: 909.930.1822
Email: gsingleton@nixonegli.com

CAB and CHASSIS

2023 PETERBILT 567
2,300 miles
VIN Number: 1XPCD40X1PD880522
Truck Hours: 347

Unit Details

Crane frame mounted forward of rear tandem.
A 21′ retracted to 81′ extended 5-section proportional boom.
Boom stows forward over chassis cab.
Sheave head shall be equipped with three sheaves.
Winch features a burst of speed 12,800 lb. bare drum pull with 275′ of 9’16” diameter 6×37 EIPS wire rope and a 9,600 lb. single line pull.
Radio anti-two-block and Rated Capacity Limiter (RCL) hydraulic overload protection system.
372 degree non-continuous rotation.
Hydraulic system includes 3-section gear pump (counterclockwise rotation), 50 gallon oil reservoir mounted on top of main outriggers with sight and temperature gauge, micron return filter, and single ball valve on suction line.
Dual operator control console and platforms with engine start/stop switch, independently controlled outriggers and stabilizers, bubble level gauge, signal horn, variable speed foot throttle, lifting capacity chart, range diagram chart, boom angle indicator, system pressure gauge, cup holder, and 12V power outlet.
Out-and-down type outriggers at crane pedestal with 20’0″ center to center extended span and equipped with removable ball socket aluminum pads.
“H” type rear vertical underframe stabilizers behind rear axle with 5’11” outside to outside span.
Full and mid-span outrigger load chart.
Horizontal type boom rest mounted behind cab.
Downhaul weight with hook.
Maximum tip height of 91′ and maximum lifting capacity of 18 US tons at 5′ radius.
360 degree stability.
(Requires front stabilizer)
Unit certified to ANSI B30.5 for Mobile Cranes.

Options

Front Bumper Stabilizer for 360 Degree Area of Operation. (Includes Additional Control Valve)

Automatic Rotation Lockout - Prevents Boom from Rotating to Side Where Out-and-Down Outriggers Are Not Fully Extended Horizontally.

275′ of 9/16″ Diameter Spin Resistant Wire Rope, In Lieu of Standard Wire Rope.

15-Ton Single Sheave Hook Block For 2/3 Parts of Line. (240 lbs.)

Clockwise Rotation Pump (Required for Automatic Transmission)

Vertical Holder On Truck Frame For 2/3 Part Line Hook Block
