Heavy Duty
Access, No
Compromise
G40F HIREACH
Large Platform, No Tailswing, Built to Handle More
The Elliott G40 is a rugged, no-tailswing material handling aerial work platform engineered for serious lifting and high-access performance in tight urban, rail and industrial environments. With a spacious platform, heavy-duty design, and full ANSI A92.2 compliance, the G40 delivers reliable reach, customizable configurations, and exceptional load-handling capability—without sacrificing maneuverability. Whether you need lifting power, platform space, or flexible mounting options, the G40 is built to do the job, your way.
Suggested industries
Why choose the G40F?
Why choose
the G40F?
HYDRAULIC STEEL BOOM FOR A SMOOTHER RIDE
The G40F’s steel boom extends hydraulically—no cables or chains—for a smoother, quieter ride and less long-term maintenance, even in demanding environments.
INTUITIVE PLATFORM CONTROL SYSTEM
Equipped with Elliott’s DynaSmooth platform controls, operators benefit from individual joysticks, hi/lo range sensitivity, and a foot-enable switch—designed for precision, responsiveness, and control in the air.
FREEDOM TO BOOM IN ANY DIRECTION
Unlike many competitors, the G40F has no side reach envelope limits. You can boom up, down, or out in any direction (within chart capacity), giving you more flexibility on every job.
BUILT FOR STABILITY AND LONGEVITY
An oversized turret and bearing provide superior durability, smoother rotation, and long-term structural reliability—ideal for high-frequency users in utility, sign, and lighting applications.
POWERFUL MATERIAL HANDLING OPTIONS
Add the optional main boom winch for lifting with or without the platform, or equip the 1,000 lb removable jib winch for lifting payloads directly from the basket—minimizing trips to the ground.
G40F technical specs
G40F
Technical specs
WORKING HEIGHT
45′ / 13,7 MWORKING SIDE REACH
30′ / 9,1 MBOOM SECTIONS
3PLATFORM TYPE
Top-MountPLATFORM CAPACITY
1,000 LB / 454 KGPLATFORM SIZE
40″X60″ / 102X152 CMJIB WINCH CAPACITY
1,000 LB / 454 KGMAIN WINCH CAPACITY
5,900 LB / 2,676 KGOUTRIGGER TYPE FRONT
A-TYPEOUTRIGGER SPREAD FRONT
12′6" / 3,8 MOUTRIGGER TYPE REAR
A-USOUTRIGGER SPREAD REAR
8′ / 2,4 MUNIT WEIGHT (BARE)
10,000 LB / 4536 KGOVERALL HEIGHT
11’3” / 3,4 MRECOMMENDED CAB TO AXLE (CA)
120” / 305 CMRECOMMENDED GVWR
25,999 LB / 11,793 KG45′ / 13,8 M
30′ / 9,1 M
3
Top-Mount
1,000 LB / 454 KG
40" x 60" / 102 x 152 CM
1,000 LB / 454 KG
5,900 LB / 2676 KG
A-TYPE
12’6″ / 3,8 M
A-US
8' / 2,4 M
10,000 LB / 4536 KG
11'3" / 3,4 M
120” / 305 CM
25,999 LB / 11,793 KG
MADE IN OMAHA,
TRUSTED BENEFITS
Elliott Equipment is family-owned and proudly American-built in Omaha, Nebraska. Each HiReach is designed for long-term performance with premium hydraulics, Bluetooth diagnostics, and fewer leak points, backed by a lifetime structural warranty.
Customize it for your crew
From lighting installs to bridge inspections, the G40F is made to fit your application. Add sign forks, platform lighting, composite pads, custom paint, or whatever your job demands.
Ready to see it in action?
Let’s build the perfect G40F for your team. Contact us today to talk specs, customizations, and dealer availability.
Trusted by Industry Leaders Nationwide
built to last.
lifetime warranty
Elliott Equipment Company specializes not only in flexibility and customization, but also in building some of the toughest equipment on the market. With our standard warranty, the best warranty in the industry, we can guarantee that our trucks are built to last.
Ask about our lifetime structural warranty and comprehensive one-year parts & labor warranty.
Any Questions?
OUR FAQs
Don’t see your question? Contact an expert. We’ll help you get everything sorted out!
What is the working height and platform capacity of the G40F?
The G40F offers a 45′ (13.7 m) working height and comes standard with a 40″ × 60″ platform that supports a 1,000 lb (454 kg) capacity, ideal for two-person elevated work teams.
Can I lift materials while working in the basket?
Yes. The G40F supports both an optional main boom winch and a 1,000 lb jib winch in the platform. These allow you to lift tools, equipment, or materials directly while in the platform—eliminating extra trips to the ground.
Does the G40F limit side reach directions?
No. Unlike many models, the G40F has no side reach envelope limits, enabling operators to boom up, out, or down in any direction while staying within the load chart—adding heightened flexibility on the jobsite.
What maintenance and warranty protections are included?
What is the working height and platform capacity of the G40F?
The G40F offers a 45′ (13.7 m) working height and comes standard with a 40″ × 60″ platform that supports a 1,000 lb (454 kg) capacity, ideal for two-person elevated work teams.
Can I lift materials while working in the basket?
Yes. The G40F supports both an optional main boom winch and a 1,000 lb jib winch in the platform. These allow you to lift tools, equipment, or materials directly while in the platform—eliminating extra trips to the ground.
Does the G40F limit side reach directions?
No. Unlike many models, the G40F has no side reach envelope limits, enabling operators to boom up, out, or down in any direction while staying within the load chart—adding heightened flexibility on the jobsite.
What maintenance and warranty protections are included?
The G40F features a cable-free hydraulic steel boom and an oversized turret and bearing system, ensuring fewer maintenance needs and exceptional structural durability. All G40F units are backed by a one-year parts/labor warranty plus a lifetime structural warranty for added peace of mind.
