The Industry’s Tallest Insulated Transmission Multi-Tool
E210I E-LINE
One Machine. Five Functions. Now Reaching Up to 210 Feet.
The E210I is purpose-built for extreme transmission work, delivering unmatched vertical reach—190 feet with the main boom, and 210 feet with the articulating upper boom—while maintaining the versatility, safety, and rugged durability crews rely on. Designed with direct input from utility professionals, the E210I features Elliott’s patented interchangeable boom system, giving you the ability to dig, lift, position, and access energized lines with one powerful machine. Whether you’re working on remote transmission structures or inside tight substations, the E210I maximizes productivity and ROI in every environment.
Suggested industries
Why choose the E210i?
Why choose
the E210I?
Do More with One Machine
Patented interchangeable boom system lets one unit do the work of five, reducing fleet size and maintenance.
Maximize Utilization
Easily reconfigure for different job types—minimizing idle time and maximizing ROI.
Unmatched Reach
190′ main boom reach, 210′ upper boom height—ideal for the tallest transmission structures.
Go Where Others Can’t
60° overcenter articulation enables under-the-line and between-phase access in tight or complex setups.
500kV Insulating Boom Option
Includes corona ring, VON leakage monitor, and desiccant filter for live-line applications.
Steel Boom Storage Mode
Store the fiberglass boom in a protective steel articulating boom when insulation isn’t needed.
Heavy-Duty Lifting
30,000 lb main boom capacity plus 1,000 lb platform material handling.
Fast, Safe Setup
EZ Crib outriggers provide 30″ of extra vertical reach, reducing the need for cribbing and manual lifting.
Smooth, Smart Controls
Precision operation with customizable working envelopes for increased control and safety.
Elliott-Built Durability
Reinforced components for long life and rugged jobsite performance, backed by a lifetime structural warranty.
E210I technical specs
E210I
Technical specs
WORKING HEIGHT (MAIN BOOM)
190′ / 57,9 MARTICULATING TIP HEIGHT
210′ / 64,3 MWORKING SIDE REACH
82′ / 25 MBOOM SECTIONS
5MAIN BOOM MATERIAL HANDLING CAPACITY
30,000 LB / 13 608 KGARTICULATING PLATFORM CAPACITY
600 LB / 272 KGARTICULATING PLATFORM SIZE
24″X60″ / 61X152 CMTELESCOPIC PLATFORM SIZE
40″X72″ / 102X183 CMTELESCOPIC PLATFORM CAPACITY
1,000 LB / 454 KGOUTRIGGER TYPE FRONT
EZ-CRIBOUTRIGGER SPREAD FRONT
26′2" / 8 MOUTRIGGER TYPE REAR
EZ-CRIBOUTRIGGER SPREAD REAR
26′2" / 8 MUNIT WEIGHT (BARE)
CONTACT FACTORYOVERALL HEIGHT
13’6” / 4,7 MRECOMMENDED CAB TO AXLE (CA)
221" / 561 CMRECOMMENDED GVWR
108,000 LB / 48 988 KG190′ / 57,9 M
210′ / 72,5 M
82′ / 25 M
5
30,000 LB / 13 608 KG
600 LB / 272 KG
24″X60″ / 61X152 CM
40″X72″ / 102X183 CM
1,000 LB / 454 KG
EZ-CRIB
26′2" / 8 M
EZ-CRIB
26′2" / 8 M
CONTACT FACTORY
13’6” / 4,7 M
221" / 561 CM
108,000 LB / 48 988 KG
MADE IN OMAHA,
TRUSTED BENEFITS
Elliott Equipment is employee-owned and proudly American-built in Omaha, Nebraska. Designed to excel in utility transmission, wind, and other applications requiring extended reach, material handling capabilities, and robust construction, the E-Line is the ultimate choice for professionals who refuse to compromise.
Customize it for your crew
The Elliott E210i E-Line is built for demanding utility and transmission work, delivering class-leading reach, material-handling capability, and a spacious two-man platform. With features like proportional controls, EZ-Crib outriggers, and available options including isolating platform yokes, remote controls, climate-controlled cabs, and customizable tool circuits, the E210i ensures maximum performance, stability, and flexibility on every jobsite.
Ready to see it in action?
Let’s build the perfect E190 for your team. Contact us today to talk specs, customizations, and dealer availability.
Trusted by Industry Leaders Nationwide
built to last.
lifetime warranty
Elliott Equipment Company specializes not only in flexibility and customization, but also in building some of the toughest equipment on the market. With our standard warranty, the best warranty in the industry, we can guarantee that our trucks are built to last.
Ask about our lifetime structural warranty and comprehensive one-year parts & labor warranty.
Any Questions?
OUR FAQs
Don’t see your question? Contact an expert. We’ll help you get everything sorted out!
What are the working height and side reach of the E210i?
The Elliott E210i E-Line offers up to a 190′ main boom working height, and with an optional jib deployed, it can reach up to ~210′—providing exceptional access for utility and transmission work.
What is the platform size and capacity?
The E210i has two platform configurations, the articulating platorm with a size of 24″x60″ and capacity of 600lbs, and the telescopic platform with a size of 40″x72″ and a capacity of 1,000lbs. These allow for both personnel work and material handling.
How quickly can the E210i be set up?
The E210i uses EZ Crib outriggers, which provide extra vertical penetration to reduce the amount of cribbing required — meaning it sets up faster and with less handling of cribbing material.
Is the E210i compliant and supported by warranty?
Yes. The E210i is fully ANSI A92.2 compliant for vehicle-mounted rotating and elevating aerial devices, and backed by Elliott’s lifetime structural warranty, ensuring safety, durability, and long-term reliability.
